《第一原动天》 · PART I.

第一部·星位数字的读法 第十四至十六则 对数与推运弧的均化

第十五则用对数求第四比例数,取前六位、第七位四舍五入;第十六则把推运弧加到太阳赤经上,查星历数日,一日折一年。

CANON XIV.

The use of the Sexagenary table is to find the part proportional, and will be proved, by example, in another volume of this work, to which we refer the Reader.

CANON XV.

The Use of the Logarithms.

We have placed the logarithms of absolute numbers, because in that manner of Ptolemean direction, which we follow, they are of very great service in exhibiting the fourth proportional number; therefore the three numbers being given, whether of parts or hours; if they are minutes, let each of them be reduced to minutes, adding them as they are disposed in their places; then take the logarithms of the third and second number, add them together; from this sum substract the logarithm of the first, and look for the remainder in the middle of the table; opposite to which, take the number for the fourth required, which divide by 60, and with the remainder you will have parts or hours with their minutes.

For example; let the numbers be given, the first 95, 25, the second 45, the third 100, 15, reduced to minutes are 5725—2145—6615; the logarithms of the first 375÷778, of the second 333.143, of the third 382÷053. I add the second and third together, and I make the sum 715196, from which I substract the first, and there remains the logarithm 339418, answering to the number 2478, which, reduced to degrees, makes 41° 18', the fourth number required.

黑像陶瓶画:两位学者对坐,一人报数,一人在板上加减
求第四比例数
翻译点开

CANON XIV.

第十四则。

The use of the Sexagenary table is to find the part proportional, and will be proved, by example, in another volume of this work, to which we refer the Reader.

六十进制表的用处是求比例部分,将在本书的另一卷中用例子证明,请读者参阅。

CANON XV.

第十五则。

The Use of the Logarithms.

对数的用法。

We have placed the logarithms of absolute numbers, because in that manner of Ptolemean direction, which we follow, they are of very great service in exhibiting the fourth proportional number; therefore the three numbers being given, whether of parts or hours; if they are minutes, let each of them be reduced to minutes, adding them as they are disposed in their places; then take the logarithms of the third and second number, add them together; from this sum substract the logarithm of the first, and look for the remainder in the middle of the table; opposite to which, take the number for the fourth required, which divide by 60, and with the remainder you will have parts or hours with their minutes.

我们列出了绝对数的对数,因为在我们所遵循的托勒密式推运方法中,它们在求第四比例数上用处极大;所以,给定三个数,无论是度还是时;若带有分,就把每个数都化为分,按它们各自所处的位置加起来;然后取第三个数与第二个数的对数,相加;从这和数中减去第一个数的对数,在表的中间找这余数;与之相对,取所求第四个数的数,除以六十,商与余数就得到度或时及其分。

For example; let the numbers be given, the first 95, 25, the second 45, the third 100, 15, reduced to minutes are 5725—2145—6615; the logarithms of the first 375÷778, of the second 333.143, of the third 382÷053. I add the second and third together, and I make the sum 715196, from which I substract the first, and there remains the logarithm 339418, answering to the number 2478, which, reduced to degrees, makes 41° 18', the fourth number required.

例如:设给定三个数,第一个九十五、二十五,第二个四十五,第三个一百、十五,化为分是五千七百二十五、二千一百四十五、六千六百一十五;第一个的对数是三七五七七八,第二个的是三三三一四三,第三个的是三八二〇五三。我把第二个与第三个相加,得和数七一五一九六,从中减去第一个,剩下对数三三九四一八,对应的数是二千四百七十八,化为度,得四十一度十八分,就是所求的第四个数。

大意与图解点开

🔎 大意:推运处处要用比例三率求第四个数。都化为分后,第二、第三数的对数相加,减第一数的对数,反查得第四数,再除以六十。

📖 术语

术语英文原词意思
对数logarithms化乘除为加减的数
绝对数absolute numbers普通的整数
第四比例数fourth proportional number比例三率所求之数
托勒密式推运Ptolemean direction按半弧比例的推运
表的中间middle of the table对数表的表身

🧭 图解与讲解

第十四则讲六十进制表,原书只说留待另一卷用例子说明;第十则已经演示过它的用法。第十五则讲对数。普拉西德斯的推运法处处要按半弧的比例求距离,即比例三率:已知三个数,求第四个数。对数把其中的乘除化为加减(图二):第二、第三两数的对数相加,减去第一数的对数,反查即得。

原书例:95°25′ ∶ 35°45′ = 110°15′ ∶ ?
步骤算什么用哪个数结果
一三个数化为分95°25′、原书印作 45(实为 35°45′)、原书印作 100°15′(实为 110°15′)5725、2145、6615
二查三个数的对数(取六位)对数表375778、333143、382053
三第二、第三数的对数相加333143 + 382053715196
四减去第一数的对数715196 − 375778339418
五在表中反查339418 对应的数2478
六除以六十,化为度分2478 ÷ 6041°18′

〔图〕对数把比例三率的乘除化为加减

原书的例子(表一):三个数化为分是五千七百二十五、二千一百四十五、六千六百一十五,查得对数,加减得三三九四一八,反查是二千四百七十八分,即四十一度十八分。用的是对数的尾数,首位的整数部分略去不写。这是推运中常见的题型:一颗星半弧九十五度二十五分时距离三十五度四十五分,半弧一百一十度十五分时距离多少。

原书此处数字疑有误:第二个数印作「四十五」,第三个数印作「一百、十五」,但化为分的二千一百四十五、六千六百一十五,分别是三十五度四十五分与一百一十度十五分;后面的对数与结果都按后者算,验算无误。本站照印原文。

But because the logarithm of eight figures, the six first of these are sufficient for this purpose, and it seemed not good to rescind the rest, by reason of other advantages resulting from them: you may only make use of the six first, with provision, if you think proper, for it is of little use or consequence; but if the seventh figure be five or greater, you should add the unity to the six figures, which will be your last; and if the seven figures be 4, 3, 2, 1, 0, omit it entirely.

In the given example of the first number 5725, the logarithm is eight figures, 37577755, I leave out the the two last figures 55, and add the unit to the six, which make it 375778. Observe also, that the logarithms are easier collected by taking two figures for every change; thus first collect 37, then 57, lastly 78.

翻译点开

But because the logarithm of eight figures, the six first of these are sufficient for this purpose, and it seemed not good to rescind the rest, by reason of other advantages resulting from them: you may only make use of the six first, with provision, if you think proper, for it is of little use or consequence; but if the seventh figure be five or greater, you should add the unity to the six figures, which will be your last; and if the seven figures be 4, 3, 2, 1, 0, omit it entirely.

但因为对数有八位数字,前六位对此已经足够,而把其余的删去似乎不好,因为它们另有别的用处:你若认为合适,可以只用前六位,留有余地,因为〔后两位〕用处不大、关系不大;但若第七位是五或更大,就应在六位数上加一,作为你的末位;若第七位是四、三、二、一、〇,就完全略去。

In the given example of the first number 5725, the logarithm is eight figures, 37577755, I leave out the the two last figures 55, and add the unit to the six, which make it 375778. Observe also, that the logarithms are easier collected by taking two figures for every change; thus first collect 37, then 57, lastly 78.

在所给的例子中,第一个数五千七百二十五的对数是八位数三七五七七七五五,我略去最后两位五五,在第六位上加一,就成为三七五七七八。还要注意,每次取两位数,对数更容易收集;如先取三七,再取五七,最后七八。

大意与图解点开

🔎 大意:表中对数有八位,推运只需前六位:第七位五以上进一,四以下舍去。五千七百二十五的对数取作三七五七七八。

📖 术语

术语英文原词意思
八位数字eight figures表中对数的位数
末位last第六位
加一add the unity即进位
收集collected读取、抄录
删去rescind截去不要

🧭 图解与讲解

原书对数表列到八位,普拉西德斯说推运只需前六位;截去时看第七位:五或以上,第六位加一;四或以下,直接舍去(表一)。这就是今天的四舍五入。例中五千七百二十五的对数三七五七七七五五,第七位是五,所以取三七五七七八。

第十五则:六位对数的取法,即今天所说的四舍五入
步骤做法例:5725 的对数
一查表得八位37577755
二看第七位第七位是 5
三五以上,第六位加一;四以下,舍去375777 → 375778
四抄录时两位一组37、57、78

〔图〕第七位决定进位还是舍去

最后一句是抄数的小窍门:两位一组读取,「三七、五七、七八」,不易看错。这类细节说明本书原是写给学生的实用手册:致读者一章已说,《天的哲学》是为学者写的论辩,本书是为学生写的算法。

CANON XVI.

To equalize the Arc of Direction.

Add the arc of direction to the right ascension of the natural Sun, look for this sum in the middle of the table of right ascensions under the ecliptic, and take the degree and minute of longitude corresponding with that sum; then in the best Ephemeris reckon in how many days the Sun from the day and hour of birth, has arrived at that degree and minute. The number of days indicate as many years; every two hours over reckon a month; for in the nativities which follow, the example is explained.

黑像陶瓶画:老者翻开星历,逐日数着太阳的行程
天数表示同样多的年
翻译点开

CANON XVI.

第十六则。

To equalize the Arc of Direction.

均化推运弧。

Add the arc of direction to the right ascension of the natural Sun, look for this sum in the middle of the table of right ascensions under the ecliptic, and take the degree and minute of longitude corresponding with that sum; then in the best Ephemeris reckon in how many days the Sun from the day and hour of birth, has arrived at that degree and minute. The number of days indicate as many years; every two hours over reckon a month; for in the nativities which follow, the example is explained.

把推运弧加到本命太阳的赤经上,在黄道的赤经表中间找这个和数,取与之对应的黄经度与分;再在最好的星历中数一数,太阳从出生的日子与时刻起,要多少天才到达那个度与分。天数表示同样多的年;多出来的每两小时算一个月;后面所列的本命中有例子说明。

大意与图解点开

🔎 大意:推运弧加太阳赤经,还原为黄经;查星历看太阳出生后几天走到那里,几天就是几岁,余下每两小时算一个月。

📖 术语

术语英文原词意思
均化equalize, equation把推运弧折算成年岁
本命太阳natural Sun出生时的太阳
星历Ephemeris逐日列行星位置的书
两小时一个月every two hours a month一日二十四时对十二个月
推运弧arc of direction推运所走的赤道度数

🧭 图解与讲解

第十六则讲「均化」推运弧,即把推运弧折算成年岁。普拉西德斯不用「一度一年」的粗法,而照第一部第五十八、六十五条:出生后第几天太阳在正球上升起的赤经,对应第几年。所以把推运弧加到本命太阳的赤经上,还原为黄经,再查星历,看太阳出生后几天走到那一度;几天就是几岁,多出的每两小时算一个月(图一)。

〔图〕推运弧怎样折算成年岁

示例:第十九则法凯内蒂枢机主教本命,太阳到木星五分的推运
步骤算什么用哪个数结果
一推运弧第十九则算得15°13′
二加到本命太阳的赤经上0°8′ + 15°13′15°21′
三在赤经表中还原为黄经赤经 15°21′白羊 16°40′
四查星历:太阳出生后几天到白羊 16°40′星历十六天多几小时
五一天一年,两小时一个月—约十六岁

后面第十九则正有一例(表二):法凯内蒂枢机主教的太阳推运到木星的五分,推运弧十五度十三分;加到太阳的赤经零度八分上得十五度二十一分,还原为白羊十六度四十分;太阳出生后十六天多才走到那里,所以应在十六岁上下。这种折算比「一度一年」细致,因为太阳每日在赤经上所行并不相等;其根据就是第一部的「一天对应一年」。

原文为公有领域古籍;翻译、印象画与图文解读由 AI 辅助生成,鲲侯审校。
